Product Parameter:

Performance parameters picture sensor 640⋆480 COMS

Decode capacity 1D Codabar Code 39 Code 32 Code 93 Code 128 GS1-128 UPC-A UPC-E EAN/JAN-8 EAN/JAN-13 GS1 Data Bar RSS14 GS1 Databar limited GS1 Databar Expanded Interleaved 2 of 5 ITF5 Industrial 2 of 5 Matrix 2 of 5 2D PDF417 QR Code Data matrix depth of field Tested Code

Minimum Maximum Code39 6.6mil 5cm 16cm EAN13 15.6mil 5cm 26cm

QR10mil 3cm 7cm DM 15mil 4cm 15cm System Compability Linux WindowsXP Windows 7 Windows 8 Windows 10 MAC Type of light 675nm ±3nm LED illumination element

Scan mode Manual button scan, auto-sensing scan

Support keyboard American English Support barcode language Simplified Chinese characters

Decode Accuracy Code 39, 5mil Code Available 1D 2D Codes printing on Paper or film or Cellphone or PC screen scanning speed 200 times/second printing contrast 25%

Secondary development not supported barcode output editing not support for adding suffixes

Scanning Angle horizontal 72° vertical 82° roll360° Human- machine interaction Indicator light The blue light is always on when power is on, and the blue light is blinking when decoding. Buzzer starting prompt, decoding success prompt button start, trigger scan environment parameters drop resistance can withstand 2 meters of free fall for 5 times.

Environmental Sealing Ip42 Working Temperature-20-55

Storage temperature range -20-60

Working Humidity 5-95% Non-Condensed
